Technical Specifications

Display

2.8 inch Color LCD

Syringes

5ml, 10ml, 20ml, 30ml & 50/60ml.

Infusion Modes

Rate Mode, Time Mode and Drug/Weight Mode

Time/Volume Mode

Volume: 9999.9ml,

Time: 99:59:59

Drug/weight Mode

Body weight: 0.1-300 kg

Drug Amount 0.01ug-999g

Solution Volume�0.1-999.9 ml

Dose: 0.01-99.99 (subject to the unit)

Flow Rate Range

5ml : 0.1ml/h-150ml/h; 10ml : 0.1ml/h-300ml/h; 20ml : 0.1ml/h-600ml/h 30ml : 0.1ml/h-900ml/h; 50ml/60 ml : 0.1ml/h-1200ml/h

Flow Rate Step

0.1ml/h

Flow Rate Accuracy

within ±2%

Volume Limit

0.1-9999.9 ml

BOLUS Rate

5ml : 10ml/h-150ml/h; 10ml : 10ml/h-300ml/h; 20ml : 10ml/h-600ml/h; 30ml : 10ml/h-900ml/h; 50ml/60ml : 10ml/h-1200ml/h

BOLUS Accuracy

≤±2% (after calibration)

Purge Rate

5ml : 150ml/h; 10ml : 300ml/h; 20ml : 600ml/h;
30ml : 900ml/h; 50ml/60ml : 1200ml/h

KVO

0.1-5ml/h (after injection)

Occlusion Level

3-level Sensitivities Setting

Audio & Visual Alarm

Clamp Err, Putter Err, Finished KVO, Near Empty, EMPTY, Occlusion Low Battery, Power OFF etc.

Power Supply

100V-240V AC，50Hz/60Hz

Battery Type

Internal rechargeable Ni-MH DC12V 2000mAh

Battery Backup

8 hours at 5ml/hr after fully recharged

Classification

Class I, CF, IPX2

Dimensions

305mm(L) X 130mm(B) X 108mm(H) (handgrip and clamp excluded)

Weight

1.9Kg Approx

Operational Conditions

Temperature: +5˚C - +40˚C

Relative Humidity ≤80%

Atmospheric Pressure 70KPa - 106Kpa

Storage & Transportation Conditions

Temperature: -22˚C - +55˚C
Relative Humidity : 10% - 90%
Atmospheric Pressure 70KPa - 106Kpa
