Display

3.2 inch Color TFT (240X320 Pixels)

IV Sets

Standard IV sets of 20d/ml and 60d/ml, with diameter 3.4-4.5mm

Infusion Modes

Rate Mode, Time Mode, Drug/ Weight Mode, Drip Rate Mode(optional)

Infusion Accuracy

≤± 5 % (after calibration)

Volume Limit

1-9999 ml

Flow Rate Range

0.1 ml/hr-1200ml/hr (20d/ml IV set)

0.1 ml/hr-1200ml/hr (20d/ml IV set)

BOLUS

Default 600ml/h, Values adjustable within 10-1200ml/hr (20d/ml IV set)

Default 150ml/h ,Values adjustable within 10-150ml/hr (60d/ml IV set)

BOLUS Accuracy

≤± 5 % (after calibration)

Purge Rate

600ml/hr (20d/ml IV set)

150ml/hr (60d/ml IV set)

KVO

0.1-10ml/hr (after infusion)

Occlusion Level

3-level Sensitivities Setting

Bubble detection

Ultrasonic with 3-level sensitivities setting, working frequency: 2MHz±5%

Effective bubble detection volume:≥0.025ml

Audio & Visual Alarm

Door open, AIR in Line, Occlusion, No operation, Power OFF, Low Battery, Battery Err, Battery Lost, AC Lost, Sensor Err, Motor Err, Circuit Err.,COM. Err, Overflowing etc.

Power Supply

100V-240V AC，50Hz/60Hz

Battery Type

Internal rechargeable Ni-MH DC12V 2000mAh

Battery Backup

4 hours at 25ml/hr after fully recharged

Classification

Class I, CF, IPX2

Dimensions

167mm(L) X 125mm(B) X 115mm(H) ( handgrip and clamp excluded)

Weight

1.8Kg Approx

Operational Conditions

Temperature: +5˚C - +40˚C

Relative Humidity ≤80%

Atmospheric Pressure 70KPa - 106Kpa

Storage & Transportation Conditions

Temperature: -22˚C - +55˚C

Relative Humidity : 10% - 90%

Atmospheric Pressure 70KPa - 106Kpa
